| New England Marine Engine |
| Author |
Message |

richarddurgee
Senior Member
Username: richarddurgee
Post Number: 552
Registered: 11-2001
| | Posted on Thursday, September 16, 2004 - 09:26 pm: |
|
This 1909 " New England Marine Engine"
has a very unique connecting rod design ??
 |
amanco
Member
Username: amanco
Post Number: 6
Registered: 07-2004
| | Posted on Friday, September 17, 2004 - 07:46 am: |
|
This open crank two-cycle design is common in oil field engines like Bessemer and Oil City engines. The back side of the cylinder is sealed around the connecting rod with a packing nut and movement is limited to non-reciprocating/linear movement by a cross head. The piston draws the fuel charge in behind it when the piston moves forward and is transferred to the front of the piston for compression thru a port in the cylinder wall when the piston travels back to bottom dead center. It is a very simple design.
~Keith in Delaware, oHIo |
|
|
|
|
